XENARC ORIGINAL D1S

The original spare parts with four-year guarantee

XENARC ORIGINAL lamps impress with a wide product range and the reliable OEM quality. Successfully used in millions of new vehicles from renowned manufacturers, whether as standard initial equipment or original spare parts. With up to 4,500 Kelvin color temperature, their light is closer to natural daylight than conventional halogen light with 3,200 Kelvin – and is thus more pleasant for the eyes. Thanks to the impressive intensity of the light, the lamps provide better visibility on the road. The durable lamps function as original spare parts of your truck lamps and convince with their long lifetime. OSRAM provides a 4-year-guarantee for XENARC ORIGINAL lamps. Please note: XENARC lamp change is recommended to be carried out by a professional.
DO NOT TOUCH FLASK SWITCH OFF HEADLIGHTS BEFORE CHANGING LAMPS HAVE ON ADEQUATE GLOVES WHEN MOUNTING AND DEMOUNTING ATTENTION HOT DO NOT DISPOSE IN DOMESTIC WASTE USE ADEQUATE EYE PROTECTION WHEN MOUNTING AND DEMOUNTING PROTECT FROM SHOWER WATER OPERATION ONLY IN LAMP WITH PROTECTIVE COVER 48091_DANGEROUS VOLTAGE 319936_NON HOUSEHOLD ILLUMINATION CAR LAMP

Technical Data

Electrical data

Power input

35 W

Nominal voltage

85.0 V

Nominal wattage

35.00 W

Power input tolerance

±3 %

Test voltage

13.5 V

Photometrical data

Luminous flux

3200 lm

Luminous flux tolerance

±15 %

Color temperature

4500 K

Dimensions & weight

Length

83.2 mm

Diameter

9 mm

Product weight

59.00 g

Lifespan

Lifespan B3

2000 h

Lifespan Tc

3000 h

Guarantee

4 years

Additional product data

Base (standard designation)

PK32d-2

Capabilities

Technology

HID

High-intensity discharge lamp

Certificates & standards

ECE category

D1S

To be operated only with approved electronic control gear

Approval marks – approval

E1 approval

Environmental information


Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)

Date of Declaration

06-05-2022

Primary Article Identifier

4008321184450 | 4008321184276 | 4008321184474 | 4008321184252 | 4008321329295 | 4008321584816 | 4052899036574 | 4052899600423 | 4062172078740 | 4062172078726 | 4062172078702 | 4062172078689

Candidate List Substance 1

leadLead

CAS No. of substance 1

7439-92-1

Safe Use Instruction

The identification of the Candidate List substance is sufficient to allow safe use of the article.

Declaration No. in SCIP database

e5f667df-3f2b-486e-86db-e76bb778ba5a | d77cbbd7-7150-4270-8d80-8d074bdf807b | 4a147db5-14f7-463f-899f-bee85333f0b0 | 31336244-710b-47dc-bdf3-6d8e2c776b82 | 60477ddf-db67-4cc2-bd70-dfcdac6fb90d | a9e37cbd-eb09-43c9-8f5e-6cc733f299b2 | 055423ab-fc23-4399-9fa1-c773a2e18475 | 9aaef5e5-deb6-4a3c-8e15-eaa63c9f017b | a7f8360d-3aae-4fda-94ee-1571431ce2ad | fd46009f-7d87-458a-a042-02761bfcff85 | 76b60f0a-2058-4902-a1ed-0486e0da9b7b | e88095ba-ba24-47f9-a9e6-67cf6f88eeda

Packaging information

EAN

Unit

Piece

Dimension l x w x h

Weight

Volume

4008321184276 FS

Folding box

1 53mm x 46mm x 93mm 81.00g 0.23dm³
4052899600423 SCB

Soft cover box

1 95mm x 51mm x 112mm 80.00g 0.54dm³
4008321874672 VS

Shipping box

4 118mm x 98mm x 97mm 432.00g 1.12dm³
4052899600430 VS

Shipping box

4 216mm x 106mm x 150mm 405.00g 3.43dm³
